Page 2SKU 44846
Specifications
Save This Manual
You will need the manual for the safety warnings and precautions, assembly instructions,
operating and maintenance procedures, parts list and diagram. Keep your invoice with this
manual. Write the invoice number on the inside of the front cover. Keep the manual and
invoice in a safe and dry place for future reference.
Safety Warnings and Precautions
WARNING: When using tool, basic safety precautions should always be followed to
reduce the risk of personal injury and damage to equipment.
Read all instructions before using this tool!
1. Keep work area clean. Cluttered areas invite injuries.
2. Observe work area conditions. Do not use machines or power tools in damp or wet
locations. Don’t expose to rain. Keep work area well lighted. Do not use electrically
powered tools in the presence of flammable gases or liquids.
3. Keep children away. Children must never be allowed in the work area. Do not let
them handle machines, tools, or extension cords.
4. Store idle equipment. When not in use, tools must be stored in a dry location to
inhibit rust. Always lock up tools and keep out of reach of children.
# 86PJ
E105017
Rev 10b
ITEM DESCRIPTION
Motor 120 VAC, 60 Hz, single phase, 1/3 HP, 1700
RPM, 3 amps
Spindle Speeds 620, 110, 1720, 2340, 3100 RPM
Spindle Stroke 3 inches
Spindle Taper MT2
Spindle to Base Distance 50-1/4 incles (maximum)
Spindle to Table Distance 28-1/4 inches
Column 3.12 (diameter) x 52-3/8 (H) inches
Head to Base
Base Dimensions 10-1/2 (W) x 17-3/4 (L) inches; Slot 1/2 (W)
x 5-1/2 (L) inches
Overall Dimensions 64-7/8 (H) x 33 (L) x 7-1/2 (W) inches
Chuck Taper: JT-3; Size: 5/8”
Table Slot 5/8 (W) x 3 (L) inches
Table Rotation 360°; Tilt: 45° (left and right)
Head Tilts 0° -40° -90°
Radial Travel 12 inches
Table Size 11-7/8 (diameter) inches
Weight 135 lbs.
