Page 2SKU 44991
Specifications
ITEM DESCRIPTION
Power Consumption 120 VAC, 60 Hz, single phase
Motor 4/5 HP
Speed Ranges 0 ~ 1100 low RPM and 0 ~ 2500 high RPM
Spindle R-8 Taper
Chuck JT33 Taper; 7/64 to 1/2 inch capacity
End Mill Capacity 1/2 inch
Face Mill Capacity 1 inch
Drill Capacity 1/2 inch
Micro Feed Scale 0.002 inch per line
Depth Scale 0 to 12 inches in 1/16 inch increments
Table Slot Width 1/2 inch
Table Size 15-7/8 (L) x 3-11/16 (W) inches
Unit Height 33-11/16 inches
Weight 115 lbs.
Save This Manual
You will need the manual for the safety warnings and precautions, assembly instructions,
operating and maintenance procedures, parts list and diagram. Keep your invoice with this
manual. Write the invoice number on the inside of the front cover. Keep the manual and
invoice in a safe and dry place for future reference.
Safety Warnings and Precautions
WARNING: When using tool, basic safety precautions should always be followed to
reduce the risk of personal injury and damage to equipment.
Read all instructions before using this tool!
1. Keep work area clean. Cluttered areas invite injuries.
2. Observe work area conditions. Do not use machines or power tools in damp or wet
locations. Don’t expose to rain. Keep work area well lighted. Do not use electrically
powered tools in the presence of flammable gases or liquids.
3. Keep children away. Children must never be allowed in the work area. Do not let
them handle machines, tools, or extension cords.
4. Store idle equipment. When not in use, tools must be stored in a dry location to
inhibit rust. Always lock up tools and keep out of reach of children.
5. Do not force tool. It will do the job better and more safely at the rate for which it was
intended. Do not use inappropriate attachments in an attempt to exceed the tool
capacity.
