For technical questions, please call 1-800-444 3353. Item 67853
Pump Parts List
Part Description Qty
1 Bolt M12×55 1
2 Spring Washer 12 1
3 Flat Washer 1
4 Drive Pulley 1
5 Oil Seal Circle 1
6 Flange Plate 1
7 O-ringφ85 1
8 Bearing 1
9 Bolt M12×40 6
10 Oil Breather 1
11 Crank Case End Cover 1
12 Flat Key 1
13 Crankshaft 1
14 Bearing 1
15 Gasket 1
16 Crankcase 1
17 Oil Plug 1
18 Gasket 1
19 Oil Sight Glass 1
20 Drain Oil Bolt 1
21 Second Stage Cylinder Head 1
22 Bolt M12×40 4
23 Spring Washer 12 4
24 Gasket 1
25 Connecting Rod A 1
26 Connecting Rod B 1
27 Bearing Shell 2
28 Spring Washer 10 4
29 Bolt M10×55 2
30 Bushing 1
31 Clip 2
32 Pin 1
33 Piston 1
34 Wiper Ring 2
35 Piston Ring 2
36 Gasket 1
37 Valve 1
38 Aluminum Seal 1
39 Bolt M6×25 4
40 Valve Stop Block 4
41 Spring 8
42 Valve Plate 4
43 Nut M6 4
44 Lock Nut 1
45 Elbow 1
46 Taper Sleeve 1
47 Nut 1
Part Description Qty
48 Brass Tube 1
49 Cylinder Head 1
50 Spring Washer 4
51 Bolt M10×65 4
52 Bolt M8×60 1
53 Spring Washer 10 1
54 Nut 1
55 Elbow 1
56 Bolt M8×35 2
57 Spring Washer 8 2
58 Gasket 1
59 Radiator 1
60 Connector 1
61 First Stage Cylinder Head 1
62 Bolt M12×40 4
63 Spring Washer 12 4
64 Gasket 1
65 Bushing 2
66 Connecting Rod A 1
67 Connecting Rod B 1
68 Spring Washer 10 2
69 Bolt M10×55 2
70 Bushing 1
71 Wiper Ring 2
72 Piston 1
73 Pin 1
74 Clip 2
75 Piston Ring 2
76 Gasket 1
77 Valve 1
78 Aluminum Seal 1
79 Bolt M8×30 4
80 Spring 8
81 Restrictor 4
82 Valve Plate 4
83 Nut M8 4
84 Air Filter Assembly 1
85 Cylinder Head 1
86 Spring Washer 12 4
87 Bolt M12×70 4
88 Spring Washer 8 4
89 Bolt M8×70 4
90 Nut 1
91 Pump Safety Valve 1
92 Elbow 1
93 Taper Sleeve 1
94 Nut 1
