Page 14 For technical questions, please call 1-800-444-3353. SKU 68169
Part Description Qty.
1 Screw (M6x25) 1
2 Chuck Key 1
3 Chuck 1
4 Spindle 1
5 Spindle Key (3x10mm) 1
6 Circlip (M23) 1
7 Bearing (6002) 1
8 Front Gear 1
9 Back Gear 1
10 Gear box 1
11 Screw (ST4x20) 4
12 Circlip (M22) 1
13 Oil Seal 1
14 Inner Gear 1
15 Circlip (M12) 1
16 Spring 1
17 Seal Ring 1
18 Oil Seal 1
19 Support 1
20 Bearing (608) 1
21 Rotor 1
22 Bearing (607) 1
23 Impact Selector 1
Part Description Qty.
24 Spring Cap 1
25 Spring 1
26 Mode Selector 1
27 Bearing (607) 1
28 Stator 1
29 Housing 1
30 O-Ring 1
31 Inductor 1
32 Trigger 1
33 Cord Clamp 1
34 Screw (ST4x14) 2
35 Power Cord 1
36 Cord Sleeve 1
37 Screw (ST2.9x12) 4
38 Carbon Brush 2
39 Brush Holder 2
40 Direction Switch 1
41 Capacitor 1
42 Screw (ST4x22) 1
43 Housing 1
44 Screw (ST4.2x16) 6
45 Depth Gauge 1
46 Side Handle 1
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE
OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED
TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR
EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY
CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK
AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT
PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
PARTS LIST
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not available
individually as replacement parts.
