SKU 90120 For technical questions, please call 1-800-444-3353. PAGE 10
5. A Charging Indicator Light on the Charger (34) will illuminate to show that charging
is taking place.
NOTE: The Charger (34) will not automatically turn off when the
Battery Pack is fully charged, and the Charging Indicator Light will remain on until
the Charger is disconnected from the electrical outlet. Recharging the Battery Pack
more than 5 hours can cause damage to the battery cells.
6. While charging, the Battery Pack (4), Charger (34), and Charger Adapter (35) may
become warm to the touch. This is normal, and does not indicate a problem.
7. Once the Battery Pack (4) is fully charged, disconnect the Charger Adapter (35)
from the electrical outlet. Then, disconnect the Charger Adapter (35) and Battery
Pack (4) from the Charger.
BATTERY
PACK (4)
120 VOLT
ELECTRICAL
OUTLET
CHARGER
ADAPTER
(35)
CHARGER
(34)
FIGURE D
3. When the Battery Pack (4) requires recharging, a 3 to 5 hour charge allows the tool
to operate at full power.
Do not recharge the Battery Pack longer than 5 hours, as
damage to the Battery Pack and/or Cordless Drill will occur.
4. Charging room temperature: 50
°
F – 104
°
F. Insert the Battery Pack (4) into the
Charger (34). Next, plug the Charger Adapter (35) into the socket on the side of the
Charger (34). Then, plug the Charger Adapter (35) into the nearest 120 volt,
grounded, electrical outlet. (See Figure D, below.)
