PRODUCT SPECIFICATIONS
SAVE THIS MANUAL
You will need this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures, parts list and as-
sembly diagram. Keep your invoice with this manual. Write the invoice number
on the inside of the front cover. Keep this manual and invoice in a safe and dry
place for future reference.
GENERAL SAFETY RULES
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS
Failure to follow all instructions listed below may result in
electric shock, fire, and/or serious injury.
SAVE THESE INSTRUCTIONS
WORK AREA
1. Keep your work area clean and well lit. Cluttered benches and dark areas
invite accidents.
2. Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases, or dust. Power tools create sparks
which may ignite the dust or fumes.
3. Keep bystanders, children, and visitors away while operating a power tool.
Distractions can cause you to lose control. Protect others in the work area from
debris such as chips and sparks. Provide barriers or shields as needed.
SKU 91176 PAGE 2 REV 10/04
Chuck Type 1/2” - Keyless Chuck
Revolutions Per Minute 0-500 RPM (low), 0-1600 RPM (high)
Torque Settings 7 (from 4.4 to 70.7 in.-Lbs.)
Refer to
Torque Settings
chart on page 12.
Battery 18 VDC, Rechargeable NiCd
Weight (Drill Only) 5 Lbs.
Kit includes: Case, 5 drill bits, 5 driver bits, 2” Long Extender
Adapter/Charger.
