Page 6SKU 92403
For technical questions, please call 1-800-444-3353
SETUP
Note: Before operating, make sure the Compressor is set up in a well-ventilated area, on a
flat, level, solid surface well away from any flammable objects, such as drapes. Never paint
in an area without proper ventilation, or near possible ignition sources.
Operation
Insert the Plug (1) into a power outlet.
When you are completely ready, turn on the Compressor by moving the rocker Switch
(5).
Air pressure is regulated using the Adjusting Screw (29). Loosening the Adjusting
Screw allows excess pressure to escape through the valve in the center. Tightening
the Adjusting Screw increases the pressure built up before air blows out through the
valve. Read the pressure level on the Pressure Meter (37).
Caution! The Adjusting Screw (29) can come out if loosened excessively.
Shut off the Compressor after use.
1.
2.
3.
4.
REV 05c, 07d
Air Outlet (38)
Cord (2)
Drain (43)
Switch (5)
Handle (33)
Pressure Meter (37)
Filter (42)
FIGURE 1
Adjusting
Screw (29)
