Harbor Freight Tools 92917 Nail Gun User Manual



SKU 92917 & 93253 For technical questions, please call 1-800-444-3353. Page 13
PARTS LIST
NOTE:
Some parts are listed and shown for illustration purposes only, and are not available individually
as replacement parts.
REV 11/05
Part Description
1 Screw
2 Exhaust Cover
3 Screw
4 Screw
5 Cap
6 Packing
7 Ring
8 Head Cap
9 Compression Spring
10 O-Ring
11 Head Valve
12 O-Ring
13 Cylinder Ring
14 Screw
15 Washer
16 Piston Head
17 O-Ring
18 Driver Blade
19 Screw
20 Cylinder Plate
21 O-Ring
22 Cylinder
23 O-Ring
24 Cylinder Ring
25 O-Ring
26 Bumper
27 Push Lever
28 Screw
29 Flake
30 Spring
31 Cover Plate
32 Nose (Bottom Plate)
33 Feed Pawl (A)
34 Pin Guide
35 Spring
Part Description
36 Feed Piston
37 Spring Guide
38 O-Ring
39 O-Ring
40 Spring
41 Spring
42 Spring Guide
43 Piston Stopper
44 Piston
45 Ring
46 Pin Guide
47 Ring
48 Pin
49 Screw
50 Screw
51 Feed Pawl (B)
52 Spring
53 Door
54 Pin
55 Pin
56 Pin Guide
57 Spring
58 Latch Door
59 Pin
60 Trigger Valve
61 O-Ring
62 O-Ring
63 Trigger Valve Cover
64 O-Ring
65 Trigger Plunger
66 Spring
67 O-Ring
68 O-Ring
69 Valve Bushing
70 Flake
Part Description
71 Pin
72 Pin
73 Trigger (A)
74 Pin
75 Trigger (B)
76 Screw
77 Screw
78 Grip Handle
79 Body
80 Spring
81 Filter Unit
82 End Cap
83 Air Plug (not included)
84 Canister Cover
85 Receiver (B)
86 Canister Platform
87 Canister Guide
88 Spring
89 Pin Guide
90 Canister
91 Pin
92 Ring
93 Screw
94 Platform Canister
95 Trigger
96 Bracket
97 5 mm Hex Wrench*
98 Pneumatic Tool Oil*
99 120 Piece Nail Coil*
100 Carrying Case*
P1
Driver Ass’y
Includes parts 14-18
P2
Trigger Ass’y
Includes parts 25 and 59-69
*Not shown on diagram
When ordering parts, specify which model number they are for.
