FUNCTIONS
The 18 Volt Cordless Circular Saw has the following features, as shown
in Fig. 3 below.
(K) Lower Blade Guard
(L) Light Holder
(M) Base Plate
(N) Depth Adjustment Knob
(next to the motor of the saw
not shown)
(O) Charger Base (shown on
page 16)
(P) Hex Key (Inserted in Saw
Body next to motor)
(Q) Retention Bolt
(R) Dust Port
(A) Trigger Release Button
(B) Trigger Switch
(C) Work Lamp Switch
(D) Off hand handle
(E) Laser Guide
(F) Work Light
(G) Bevel Cut Adjustment Knob
(H) 18 volt NiMh Battery
(I) Blade Flange and bolt
(J) Spindle Lock for blade change
(between saw body and upper
blade guard)
A
H
C
B
F
I
G
Figure 3
J
E
K
L
N
D
Q
P
R
