SKU 94847 For technical questions, please call 1-800-444-3353
REV 07j
Specications
Speed 875 - 1350 BPM
Operating Air Pressure 50 to 100 (maximum) PSI; 4 SCFM
Air Inlet 1/4”, 18 NPT, female
Overall Dimensions 23 (L) x 5-1/2 (W) x 24 (H) inches (C-frame and
Hammer)
Anvil-to-Hammer Opening 4 inches (maximum)
Anvil Height Adjustment 2-position anvil shaft mount with lock pin
3/8” to 1-1/4” opening (between head and anvil); 4-
position, stepped anvil micro-adjustment block 1/16”
height difference between each level
Anvil Sizes 1” Radius, 2” Radius and 3” Radius
Throat Depth 19-5/8 inches
Foot Pedal 7-1/4 (L) x 4 (W) x 3-1/2 (H) inches. Built-in air lter
Save This Manual
You will need the manual for the safety warnings and precautions, assembly instructions,
operating and maintenance procedures, parts list and diagram. Keep your invoice with this
manual. Write the invoice number on the inside of the front cover. Keep the manual and
invoice in a safe and dry place for future reference.
Safety Warnings and Precautions
WARNING: When using tool, basic safety precautions should always be followed to
reduce the risk of personal injury and damage to equipment.
Read all instructions before using this tool!
Keep work area clean. Cluttered areas invite injuries.
Observe work area conditions. Do not use machines or power tools in damp
or wet locations. Don’t expose to rain. Keep work area well lighted. Do not use
electrically powered tools in the presence of ammable gases or liquids.
Keep children away. Children must never be allowed in the work area. Do not let
them handle machines, tools, or extension cords.
Store idle equipment. When not in use, tools must be stored in a dry location to
inhibit rust. Always lock up tools and keep out of reach of children.
Use the right tool for the job. Do not attempt to force a small tool or attachment to
do the work of a larger industrial tool. There are certain applications for which this
tool was designed. It will do the job better and more safely at the rate for which it
was intended. Do not modify this tool and do not use this tool for a purpose for which
it was not intended.
Use eye and ear protection. Always wear ANSI approved impact safety goggles.
Wear a full face shield if you are producing metal lings.
Dress properly. Do not wear loose clothing or jewelry as they can be caught in
moving parts. Protective, electrically non-conductive clothes and non-skid footwear
are recommended when working. Wear restrictive hair covering to contain long hair.
1.
2.
3.
4.
5.
6.
7.
