Page 6
SKU 94847
For technical questions, please call 1-800-444-3353
Operation
1. To change the height of the Anvil (5) to within 1-1/2 inches of the desired height,
pull out Stopper Pin (9), and move the Adjustable Pole (7) up or down to one of two
Stopper Pin holes. Replace Stopper Pin.
2. To adjust closer to the desired height, move the Range Adjust Block (6) to the right or
left to reach the desired height.
3. Turn on the Air Compressor and set its regulator to 90 PSI.
4. Before planishing, test the operation by pressing down on the foot Switch Assy (13)
with your foot.
5. Adjust the cycle speed of the Air Hammer by turning the Regulator (11) valve
clockwise or counterclockwise.
6. Use both gloved hands to hold the material to be planished and place it between the
Anvil (5) and the Hammer Head (3).
7. Press down on the Switch Assy (13) on the oor with your foot to operate.
8. When nished planishing, remove your foot from the Switch Assy, and wait for the Air
Hammer to stop completely.
9. Turn the Air Compressor off.
10. Press down on the Switch Assy (13) again to release any remain air pressure in the
Air Hammer.
Changing Anvils
1. Unscrew Screw (2) so it is out of the way of the Air Hammer (10) when removing it
from the “C” Frame. Do not remove Screw (2). See photo on page 5, bottom-right.
2. Screw off the Coil Spring from the Air Hammer (10) and slip it off, along with the
Hammer Head (3) and Hammer Sleeve (4). See photo on page 5, bottom-left.
3. Slide the Air Hammer body out of the “C” Frame mounting hole.
4. Replace Anvil (5) with desired size onto the Adjustable Pole (7).
5. Replace the Air Hammer into the “C” Frame. Then, attach the Hammer Head (3)
through the Coil Spring, then into the Air Hammer. Screw on the Coil Spring until it
stops.
6. Retighten Screw (2) completely.
Troubleshooting
Problem Probable Cause Solution
Planishing Hammer does not
operate when Switch pressed
No air pressure in air line Check air line and compressor
Planishing Hammer operates
at diminished pressure
Air pressure below normal
operating pressure
Check regulator on
compressor and Air Hammer
