SKU 95094 For technical questions, please call 1-800-444-3353. PAGE 13
PARTS LIST
Part Description Q’ty
1
Chuck 1
2
Plate 1
3
Torque Setting Ring 1
4
Radiator 1
5
Upper Orientation Block 1
6
Lower Orientation Block 1
7
Locking Lever 1
8
Orienting Plate 1
9
Spring 1
10
Trigger 1
11
Bushing 1
12
Steel Ball
13
Battery Terminal Clamp 1
14
Gear Housing 1
15
Left Housing 1
16
Motor Support 1
17
Screw
18
Drive Gear 1
19
Motor 1
20
Right Housing 1
21
Charger 1
22
AC/DC Adapter 1
23
Battery Pack 1
Part Description Q’ty
24
Terminal 2
25
Terminal Mount 1
26
Battery Button Lock 2
27
Battery Cell 12
28
Battery Lower Housing 1
29
Screw
30
Battery Button Spring 2
31
Ribbed Block 1
32
Chuck Screw 1
33
Screw 3
34
Washer 1
35
Clip 1
36
Washer 1
37
Washer 1
38
Steel Ball
39
Gear Cage 1
40
Planetary Gear 3
41
Outer Gear 1
42
Sun Gear 1
43
Planetary Gear 3
44
Gear Housing Cover 1
45
Screw 8
46
Upper Battery Housing 1
