SKU 95094 For technical questions, please call 1-800-444-3353. PAGE 9
UNPACKING
When unpacking, check to make sure that the product is complete and undamaged.
If any parts are missing or broken, please call Harbor Freight Tools at the number shown
on the cover of this manual as soon as possible.
CHARGING
NOTE: The Battery Pack (23) requires charging. The first charge requires 5 hours
charge time prior to using the Cordless Drill.
Note: Always switch to a fresh battery when tool performance begins to
diminish. Severe heat is most destructive to a battery; the more heat generated,
the faster the battery loses power. A battery that gets too hot can be permanently
damaged. Never over-discharge a battery by using the tool even after tool perfor-
mance is decreasing. Never attempt to discharge a tool’s battery by continuing to
pull the tool trigger. When tool performance begins to diminish, stop the tool,
recharge the battery and use the fresh battery for optimal performance.
3. When the Battery Pack (23) requires recharging, a 3 to 5 hour charge allows the
tool to operate at full power. Do not recharge the Battery Pack longer than 5 hours,
as damage to the Battery Pack and/or Cordless Drill will occur.
4. Charging room temperature: 50
°
F – 104
°
F. Insert the Battery Pack (23) into the
Charger (21). Next, plug the Charger AC/DC Adapter (22) into the socket on the
side of the Charger (21). Then, plug the Adapter (22) into the nearest 120 volt,
grounded, electrical outlet.
5. A Charging Indicator Light on the Charger (21) will illuminate to show that charging
is taking place. NOTE: The Charger (21) will not automatically turn off when the
Battery Pack is fully charged, and the Charging Indicator Light will remain on until
the Charger is disconnected from the electrical outlet. Recharging the Battery Pack
more than 5 hours can cause damage to the battery cells.
6. While charging, the Battery Pack (23), Charger (21), and Charger Adapter (22) may
become warm to the touch. This is normal, and does not indicate a problem.
7. Once the Battery Pack (23) is fully charged, disconnect the Charger Adapter (22)
from the electrical outlet. Then, disconnect the Charger Adapter (22) and Battery
Pack (23) from the Charger.
