Page 2SKU 95499
For technical questions, please call 1-800-444-3353.
07b, 07e; 09g
SPECIFICATIONS
Electrical Requirements 120 V~ / 60 Hz / 2 HP Motor / 3400 RPM
14 Rated Amps
Power Cord Type: 14 AWG x 3 C x 6’10-1/2” Long
Power Plug Type: 3 Prong Grounded
Pressure Switch Type: ON/OFF (Pull/Push)
Compressor Style Pancake Round Tank
Pump Style Single Cylinder
Maximum Air Pressure 115 PSI
Air Flow Capacity 5.8 SCFM @ 40 PSI
4.4 SCFM @ 90 PSI
Auto Turn On/Shut Off Pressure On @ 85 PSI / Pressure Off @ 115 PSI
Air Tank Capacity 4 Gallons
Air Outlet Size 1/4”-18 NPT Female Threads
Recommended Oil Type SAE 15W-30W Non-Detergent Compressor Oil
Overall Dimensions 15-3/4” Diameter x 21” High
Weight 50 lb.
SAVE THIS MANUAL
You will need this manual for the safety warnings and precautions, assembly, oper-
ating, inspection, maintenance and cleaning procedures, parts list and assembly diagram.
Keep your invoice with this manual. Write the invoice number on the inside of the front
cover. Keep this manual and invoice in a safe and dry place for future reference.
GENERAL SAFETY RULES AND PRECAUTIONS
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS
Failure to follow all instructions listed below may result in
electric shock, fire, and/or serious injury.
SAVE THESE INSTRUCTIONS
WORK AREA
Keep your work area clean and well lit. 1. Cluttered benches and dark areas invite
accidents.
Do not operate air compressors in explosive atmospheres, such as in the 2.
presence of flammable liquids, gases, or dust. Air Compressors create sparks
which may ignite the dust or fumes.
Keep bystanders, children, and visitors away while operating an air tool. 3. Dis-
tractions can cause you to lose control. Protect others in the work area from debris
such as chips and sparks. Provide barriers or shields as needed. Children should
not be allowed in the work area.
