ASSEMBLY INSTRUCTIONS
CAUTION!1. Always make sure the Compressor’s Pressure Switch (63) is in its
“STOP” position prior to performing any service, maintenance, or cleaning of the
Compressor.
2.
REGULATOR
OILER
WATER
FILTER
TO
TOOL
AIR
COMPRESSOR
FIGURE C
To extend the life of your tools and equipment, it is recommended that you install
an oiler and water filter in-line with the Air
Outlet Valve (67) of the Air Compressor.
(See Figure C.)
Prior to using the Air Compressor, the unit 3.
requires the attachment of a 1/4”-18 NPT
Female Quick Connector (not included). To
do so, wrap approximately 3” of pipe thread
sealant tape (not included) around the male
threads of the Air Outlet Valve (67). Then
firmly screw the Quck Connector into the Air
Outlet Valve (67). (See Figure D.)
QUICK
CONNECTOR
(NOT INCLUDED)
AIR OUTLET
VALVE (67)
FIGURE D
