Page 4SKU 95718
For technical questions, please call 1-800-444-3353.
UNPACKING
When unpacking, check to make sure that the item is intact and undamaged. If any
parts are missing or broken, please call Harbor Freight Tools at the number shown on the
cover of this manual as soon as possible.
ASSEMBLY INSTRUCTIONS
Note: For additional information regarding the parts listed in the following pages, refer to
the Assembly Diagram near the end of this manual.
Loading the Staples
Pinch the clip located on the end of the Magazine Unit (2). Pull out the Magazine
Unit (2)-see Figure 1.
Insert a full strip of staples into the Staple Channel (3). Insert the staples into the
Staple Channel (3) with the sharp staple tips facing up in the Staple Channel-see
Figure 2.
Push the Magazine Unit (2) back into the Staple Gun Body (1). Make certain that
the Magazine Unit (2) is pushed all the way back into place before operating the
Staple Gun.
Magazine Unit (2)
Figure 1
1.
2.
3.
