Hitachi N3804AB Router User Manual



61
1 790-259 O-Ring (I. D. 50.52) 1
2 790-260 Exhaust Cover Insert 1
3 790-261 Valve Spring 1
4 790-262 O-Ring (I. D. 9.75) 1
5 790-336 O-Ring (I. D. 49.5) 2
6 790-323 Main Valve 1
7 790-265 O-Ring (I. D. 37.67) 1
8 790-266 O-Ring (I. D. 31.34) 1
9 790-267 Piston Assy1
10 790-268 Piston 1
11 790-269 Pin 1
12 790-270 Roll Pin D4
×
14 1
13 790-272 O-Ring (I. D. 39.34) 1
14 790-273 O-Ring (I. D. 37.77) 1
15 790-271 Driver Blade 1
16 790-324 Cylinder 1
17 790-325 O-Ring (I. D. 37.82) 1
18 790-326 Piston Bumper 1
19 790-327 Circlip 2
20 790-328 Pin 1
21 790-302 Push Lever 1
22 790-276 Hex. Socket Hd. Bolt M5
×
40 4
23 790-329 Exhaust Cover 1
25 790-330 Exhaust Valve 1
26 790-280 Perforated Plate 1
27 790-281 Silencer 1
28 790-282 Perforated Plate 1
30 790-283 Gasket 1
31 790-244 Warning Label 1
32 790-331 Body 1
33 790-320 Nameplate 1
34 790-299 Driver Guide 1
35 790-303 Front Nose 1
36 790-230 O-Ring (I. D. 7.65) 2
37 790-285 Valve Bush 1
38 790-239 Sleeve 1
39 790-241 O-Ring (I. D. 2.57) 3
40 790-286 Valve Spring 1
41 790-287 Valve Shaft 1
42 Hitachi Label 1
43 790-238 Gasket 1
44 790-237 Cap 1
N5008AB
Item
No.
Code No.
45 790-288 Trigger Assy1
46 790-234 Hex. Socket Hd. Bolt M4 × 30 2
47 790-297 Nose Assy1
48 Nose 1
49 790-311 Bushing 1
50 790-298 Pin 1
51 790-312 Cover 1
52 790-289 Hex. Socket Hd. Bolt M5
×
16 2
53 790-290 Washer 2
54 790-294 Hook Plate 1
55 790-295 Spring Washer 2
56 790-296 Hex. Socket Hd. Bolt M5
×
12 2
57 790-291 Spring 1
58 790-293 Circlip 2
59 790-332 Pin 1
60 790-318 Pressure Spring 1
61 790-319 Feeder Stop 1
62 790-304 Hex. Socket Hd. Bolt M5
×
10 3
63 790-305 Blade Guide 1
64 790-306 Hex. Socket Hd. Bolt M6
×
20 4
65 790-310 Lever Spring 1
66 790-307 Lock Lever 1
67 790-308 Bushing 1
68 790-333 Hex. Socket Hd. Bolt M5
×
12 1
69 790-313 Staple Guide Assy1
70 790-314 Ribbon Spring 1
71 Staple Guide 1
72 790-315 Ribbon Spring 1
73 790-316 Staple Feeder 1
74 790-317 Spring Guide 1
75 790-334 O-Ring (I. D. 42) 1
76 790-335 Circlip 2
501 872-422 Allen Wrench for M6 Screw 1
502 944-459 Allen Wrench for M5 Screw 1
503 944-458 Allen Wrench for M4 Screw 1
504 875-769 Eye Protector 1
Part Name Qty
Item
No.
Code No. Part Name Qty
Parts are subject to change without any obligation
on the part of the HITACHI due to improvements.
