8
OPERATION
NOTE:
The information contained in this Manual is designed to assist you in the safe
operation of the Nailer.
Some illustrations in this Manual may show details or attachments that differ from
those on your own Nailer.
NAME OF PARTS
Piston O-Ring
Exhaust Cover
Driver Blade
Piston
Nose
Nail Feeder (A)
Ribbon Spring
Magazine
Nail Stopper
Cap
Air Plug (Sold separately)
Push Lever
Firing Head (Outlet)
Nail Feeder (B)
Body
Trigger
Head Guard
Switching
Device
Switching
Device
Downward
position
Switching
Device
Upward position
Nailing operation switching device
SINGLE SEQUENTIAL
ACTUATION MECHANISM
(Switching device:
upward position)
CONTACT ACTUATION
MECHANISM
(Switching device:
downward position)
