— 11 —
English
SPECIFICATIONS
Input power source Single phase: AC120V 60Hz
Charging time
Approx. 60 min.
(At a temperature of 70°F (20°C))
Charging voltage DC 7.2 V
Charging current DC 1.6 A
Weight 2.4 lbs. (1.1 kg)
NAIL SELECTION
WARNING
ⅷ Be sure to use only the genuine HITACHI nails for
the NR90GC2 or the NR90GR2. The use of any
other nails can result in tool malfunction and/or
nail breakdown, leading to serious injuries.
Only nails shown in the Table below can be driven with
this Nailer.
.113"
(2.9 mm)
2" (50 mm)
.131"
(3.3 mm)
3-1/2" (90 mm)
NR90GC2 NR90GR2
Paper collated strip nails Min. Max. Plastic-collated strip nails Min. Max.
Clipped-head nails Full-head nails
.266"
(6.8 mm)
.303"
(7.7 mm)
.113"
(2.9 mm)
2" (50 mm)
.131"
(3.3 mm)
3-1/2" (90 mm)
.286"
(7 mm)
.3"
(7.6 mm)
* This Nailer is not recommended for use with from 3" to 3-1/2" ring shank nails in pressured-treated lumber.
1.Gas Strip Nailer
Model NR90GC2 NR90GR2
Dimensions 13-21/32" × 13-29/32" × 4-1/4" 14-1/4" × 13-29/32" × 4-1/4"
Length × Height × Width (347 mm × 353 mm × 108 mm) (362 mm × 353 mm × 108 mm)
Weight 7.0 lbs. (3.2 kg) 7.2 lbs. (3.3 kg)
Includes battery and fuel cell 7.7 lbs. (3.5 kg) 7.9 lbs. (3.6 kg)
Nail capacity 37 nails (1 strip) 32-35 nails (1 strip)
Cycle rate
Intermittent: 2 – 3 nails per second
Continuous: 1,000 nails per hour
Battery
EB714S (1.4 Ah)
Ni-Cd battery, 7.2 V
Fuel Cell Type No. 728-980
……
sold separately
2. Battery Charger (UC7SD)
NOTE: The charging time may vary according to temperature and power source voltage.
