— 66 —
Item
Part Name Q’TY
No.
1 HEX. SOCKET HD. BOLT (W/FLANGE) M5×12 1
2 TOP COVER 1
3 FILTER 1
4 MOTOR 1
5 RUBBER WASHER 1
6 ROLL PIN D2.5×25 1
7 MOTOR MOUNT 1
8 MOUNT SLEEVE 1
9 SHAFT WASHER 1
10 SPARK PLUG (A) 1
11 MOTOR SPRING 1
12 HEX. SOCKET HD. BOLT M5×20 4
13 CYLINDER HEAD 1
14 O-RING (I.D 59.92) 1
15 NUT M4 2
16 WASHER M4 2
17 FAN 1
18 HEX. SOCKET HD. BOLT M4×16 4
19 CHAMBER HEAD 1
20 GASKET (A) 1
21 CHAMBER 1
22 PLUNGER O-RING 2
23 SHAFT RING 1
24 WASHER M5 2
25 SHAFT 1
26 MACHINE SCREW M4×66
27 ADAPTER 1
28 HEX. SOCKET SET SCREW M4×52
29 CHAMBER LOCK PLATE 1
30 PIN 2
31 SWITCH PLATE 1
32 O-RING (I.D. 66.27) 1
33 RETAINING RING 1
34 PISTON RING 2
35 PISTON 1
36 PISTON BUMPER 1
37 CHAMBER STOP RUBBER 2
38 CYLINDER ASS'Y 1
39 HEX. SOCKET HD. BOLT M4×10 2
40 BUFFER COVER 1
41 LEAD VALVE 1
42 MUFFLER 1
43 BLADE GUIDE 1
44 PLATE SLEEVE 2
45 SIDE PLATE 1
46 U-NUT M5 2
47 HEX. SOCKET HD. BOLT M5×50 2
48 NOSE SLEEVE 2
49 SEAL LOCK HEX. SOCKET HD. BOLT M4×10 2
50 SPRING WASHER M4 2
51 PUSHING LEVER ARM (B) 1
52 PUSHING LEVER SPRING 2
53 PUSHING LEVER CONNECTOR 1
54 CYLINDER PLATE 1
55 SEAL LOCK HEX. SOCKET HD. BOLT M5×10 2
56 U-NUT M4 2
57 PUSHING LEVER ARM (A) 1
58 SOCKET BOLT M5×10 1
62 PUSHING STOPPER 1
63 PUSHING LEVER 1
64 ADJUSTER BUSH (S) 1
65 NAME PLATE 1
66 SCREW M5 4
67 HOUSING 1
NR90GC2
Item
Part Name Q’TY
No.
68 INSULATOR SHEET 1
69 HITACHI LABEL 1
70 HOUSING ASS'Y 1
71 NYLON NUT M4 1
72 HEX. SOCKET HD. BOLT M5×15 1
73 SLEEVE 1
74 TAPPING SCREW (W/FLANGE) D4×20 5
75 HANDLE (B) ASS'Y 1
76 CAUTION PLATE 1
77 WARNING LABEL 1
78 TAPPING SCREW (W/FLANGE) D4×45 1
79 SWITCH MOUNT 1
80 SWITCH ARM 1
81 PRISM 1
82 LOCK BAR SPRING 1
83 WIRING COVER 1
84 FLAT HD. TAPPING SCREW D4 1
85 CONTROLLER 1
86 TAPPING SCREW (W/FLANGE) D4×14 3
87 TRIGGER SPRING (A) 1
88 CHAMBER LOCK BAR 1
89 ROLL PIN D2.5×10 1
90 TRIGGER INTERNAL WIRE (A) SET 1
91 SPRING (A) 1
92 WASHER (B) 1
93 HOOK (B) 1
94 ROLL PIN D3×14 1
95 BRACKET (B) 1
96 NYLON NUT M5 1
97 NAIL RAIL 1
98 MAGAZINE PLATE 1
99 CELL LEVER 1
100 LATCH 1
101 ROLL PIN D2×82
102 SPRING D3.6 1
103 CELL COVER 1
104 CELL RUBBER 1
105 BATTERY EB 714S 1
106 NAIL FEEDER (A) 1
107 TENSION PLATE (C) 1
108 SPRING 1
109 SWITCH LEVER (B) ASS'Y 1
110 PIN D2.5 1
111 LEVER STOPPER 1
112 ROLL PIN D4×28 1
113 SPRING 1
114 NAIL FEEDER (B) 1
115 RIBBON SPRING 1
116 SPRING D8 1
117 PUSHING LEVER STOPPER 1
118 HANDLE (A) 1
119 FEEDER KNOB 1
120 TAPPING SCREW (W/FLANGE) D5×20 1
121 HEX. SOCKET HD. BOLT M4×18 1
122 MAGAZINE GUARD 1
123 LABEL (A) 1
124 WIRING PLATE 1
501 CHARGER (MODEL UC 7SD) 1
502 SAFETY GLASSES 1
503 CASE 1
504 HEX. BAR WRENCH 4MM 1
04Back_NR90GC2_US 5/7/07, 19:2466
