2
SPECIFICATIONS
Blade diameter ........................................................................................... 216 mm (8-1/2”)
Hole (arbor) diameter ................................................................................. 15.88 mm (5/8”)
Max. Miter angle ......................................................................................Left 52°, Right 52°
Max. Bevel angle ......................................................................................................Left 45°
Max. Cutting capacities (H x W)
(Note)
The max. Cutting capacities may vary according to workpiece, blade and/or charging
condition.
No load speed (RPM) .......................................................................................... 2,300/min.
Dimensions (L x W x H) ..................528 mm x 430 mm x 486 mm (20-3/4” x 17” x 19-1/8”)
Net weight ................................................................................................. 10.1 kg (22.3 lbs)
• Manufacturer reserves the right to change specifications without notice.
• Specifications may differ from country to country.
Miter angle
Bevel angle
0° 45° (left)
0°
61 mm x 122 mm
(2-3/8” x 4-13/16”)
45 mm x 122 mm
(1-3/4” x 4-13/16”)
45° (left and right)
61 mm x 85 mm
(2-3/8” x 3-3/8”)
45 mm x 85 mm
(1-3/4” x 3-3/8”)
Battery Charger DC24SA DC24SA
Input A.C. only 50 Hz - 60 Hz
Output D.C. 7.2 V - 24 V
Battery Cartridge BH2420 BH2433 BH2420 BH2433
Voltage 24 V
Charging time 30 min. 60 min. 55 min. 90 min.
