10
—
IX. ACCESSORIES
Use only bits suitable for size of drill’s chuck.
MAXIMUM RECOMMENDED CAPACITIES
X. SPECIFICATIONS
MAIN UNIT
BATTERY PACK
BATTERY CHARGER
Model EY6405 EY6409 EY6432
Screw
driving
Machine screwM5M5M6
Wood screw ø 6.8 mm (17/64") ø 6.8 mm (17/64") ø 8 mm (5/16")
Self-drilling screw ø 6 mm (15/64") ø 6 mm (15/64") ø 6 mm (15/64")
Drilling
For Wood ø 27 mm (1-1/16") ø 27 mm (1-1/16") ø 36 mm (1-25/64")
For Metal ø 10 mm (3/8") ø 13 mm (1/2") ø 13 mm (1/2")
Model EY6405 EY6409 EY6432
Motor DC Motor 12 V DC Motor 15.6 V
No-load Speed
Low 400 / min (rpm.) 450 / min (rpm.)
High 1300 / min (rpm.) 1450 / min (rpm.)
Chuck Capacity
0.5 mm ~ 10 mm
(1/32" ~ 3/8")
1.0 mm ~ 13 mm
(1/16" ~ 1/2")
Max Torque
Low 22.5 Nm (230 kgf-cm, 199 in-lbs.) 31.9 Nm (325 kgf-cm, 282 in-lbs.)
High 6.3 Nm (65 kgf-cm, 56 in-lbs.) 8.8 Nm (90 kgf-cm, 78 in-lbs.)
Clutch Torque
Approx. 1.0 Nm (10 kgf-cm, 8.7 in-lbs.) ~
5.4 Nm (55 kgf-cm, 47.7 in-lbs.)
Approx. 1.0 Nm (10 kgf-cm, 8.7 in-lbs.) ~
6.9 Nm (70 kgf-cm, 61 in-lbs.)
Overall Length
202 mm
(7-61/64")
208 mm
(8-3/16")
Weight (With Battery Pack)
1.7 kg
(3.75 lbs.)
with EY9106
1.8 kg
(3.97 lbs.)
with EY9200
1.9 kg
(4.19 lbs.)
with EY9201
2.0 kg
(4.41 lbs.)
with EY9230
2.2 kg
(4.85 lbs.)
with EY9231
2.0 kg
(4.41 lbs.)
with EY9136
Model EY9106 EY9200 EY9201 EY9230 EY9231 EY9136
Storage Battery
Ni-Cd
Battery
Ni-MH
Battery
Ni-Cd
Battery
Battery Voltage 12 V DC (1.2 V x 10 cells) 15.6 V DC (1.2 V x 13 cells)
Model EY0230
Weight 0.78 kg (1.72 lbs.)
Charging Time
15.6 V 12 V 9.6 V 7.2 V Standard Charging Time
-
EY9001
EY9006
EY9080
EY9086
EY9065
EY9066
Approx. 20 min.
-
EY9101
EY9180
EY9182
-
Approx. 25 min.
EY9136
EY9106
EY9107
-
EY9168 Approx. 30 min.
EY9230 EY9200
--
Approx. 45 min.
EY9231 EY9201
--
Approx. 55 min.
