About This Guide
This guide describes the SmartNode 5200 hardware, installation and basic configuration. For detailed software
configuration information refer to the SmartWare Software Configuration Guide and the available Configura-
tion Notes.
Audience
This guide is intended for the following users:
• Operators
• Installers
• Maintenance technicians
Structure
This guide contains the following chapters and appendices:
• Chapter 1 on page 14 provides information about router features and capabilities
• Chapter 2 on page 19 contains an overview describing router operation and applications
• Chapter 3 on page 21 provides hardware installation procedures
• Chapter 4 on page 26 provides initial procedures for configuring the SmartNode router
• Chapter 5 on page 32 contains information on contacting Patton technical support for assistance
• Appendix A on page 35contains compliance information for the SmartNode
• Appendix B on page 37 contains specifications for the routers
• Appendix C on page 40 provides cable recommendations
• Appendix D on page 42 describes the router’s ports and pin-outs
• Appendix E on page 44 lists the factory configuration settings for SmartNode 5200
• Appendix F on page 49 provides license information that describes acceptable usage of the software pro-
vided with the SmartNode 5200
For best results, read the contents of this guide before you install the router.
