9
FEATURES
Fig. 2
PRODUCT SPECIFICATIONS
Blade Arbor ..............................................................5/8 in.
Blade Diameter .......................................................... 10 in.
Blade Tilt .................................................................0˚ - 45˚
Rating ...............................................120 V, AC only, 60 Hz
Input .....................................................................15 Amps
No Load Speed ....................................5,000 r/min. (RPM)
Cutting Depth at 0˚: ..............................................3-1/2 in.
Cutting Depth at 45˚: ............................................2-1/2 in.
QUICK
STOP
MITER SCALE
MITER
FENCE
SLIDING
MITER TABLE
BLADE
GUARD
STORAGE
BRACKET(S)
FRONT
RAIL
LOCKING LEVER
SWITCH
ASSEMBLY
SCALE
HEIGHT/BEVEL
ADJUSTING HANDWHEEL
BEVEL
LOCKING
LEVER
BEVEL
SCALE
RIP FENCE
TABLE
EXTENSION
OUTFEED
SUPPORT
TABLE TILT
HANDLE
ANTI-KICKBACK
PAWLS
RIVING
KNIFE
LOCK
KNOB
LEG
STAND
BEVEL
INDICATOR
