ADAM-4015/ADAM-4015T Command Table
Command
Syntax
Command Name
Command Description
Page
No.
%AANNTTCCFF
Configuration
Sets the address, baud rate, data format,
checksum status, and/or integration time for a
specified analog input module
5-4
$AA2 Configuration Status Returns the configuration parameters for the
specified analog input module
5-10
$AAF Read Firmware
Version
Return the firmware version code from the
specified analog input module
5-12
$AAM Read Module Name Return the module name from the specified
analog input module
5-13
#AA
nalog Data In
Returns the input value from a specified analog
input module in the currently configured data
format
5-14
#AAN Read Analog Input
from Channel N
Returns the input value from a specified channel
of analog input module in the currently configured
data format
5-16
$AA5VV Enable/Disable
Channels for
Multiplexing
Enable or disable the individual channels in an
analog module
5-17
$AA6 Read Channel
Status
Get the enable/disable status of all channels in
an analog module
5-18
#** Synchronized
Sampling
Orders all analog input modules to sample their
input values and store them in special registers
5-21
$AA4 Read Synchronized
Data
Returns the value that was stored in the specified
module's register after the #** command
5-22
$AAB Channel Diagnose
Diagnose channel status in over range, under
range, and wire opening
5-24
$AA0Ci Single Channel
Span Calibration
Calibrates a specified channel to correct for gain
errors
5-27
$AA1Ci Single Channel
Offset Calibration
Calibrates a specified channel to correct for offset
errors
5-28
$AA7CiRrr Single Channel
Range Configuration
Configure the input type and range of the
specified channel in an analog input module
5-29
$AA8Ci Read Single
Channel Range
Configuration
Get the input type and range of the specified
channel in an analog input module
5-30
$AAXnnnn Watchdog Timer
Setting
Set communication WDT cycle time from 0000 ~
9999 (unit: 0.1 second. if value is 0000, the
communication WDT function will be disable)
5-31
$AAY Read Watchdog
Timer Setting
Read the cycle time setting of communication
WDT
5-32
$AAS0 Internal Calibration
Internal sel
-calibration for offset and
gain errors 5-33
$AAS1 Reload default
calibrating
parameter
Reload factory default calibrating parameter to
overwrite current calibrating parameter
5-34
