ADAM-4024 Command Table
Command Syntax Command Name Command Description Page
No.
%AANNTTCCFF Configuration Set the address, output range,
baud rate, data format, slew rate
and/or checksum status
6-19
#AACn(data) Analog Data Out Directs output data to a specified
module
6-20
#AASCn(data) Set Startup Data Set data As CHn StartUp Data
6-20
#AAECn(data) Set Emergency
Stop
Set data As CHn Emergency
Stop Data
6-20
#** N/A Synchrous Sample IDI
6-20
$AA0Cn 4 mA Calibration Tells the module to store
parameters for 4 mA Calibration
6-20
$AA1Cn 20 mA Calibration
Tells the module to store
parameters for 20 mA Calibration
6-20
$AA2 Configuration
Status
Read back Module status 6-20
$AA3Cn(number of
counts)
Trim Calibration Trims specified module a number
of units up/down
6-20
$AA4 Start-up output
current/voltage
confi
uration
Stores a default output value in a
specified module. The output
value will take effect upon startup.
6-20
$AA5 Reset Status Read Back Reset Times After Last
$AA5 CMD And Clear This ounter
6-20
$AA6Cn Last Value
Readback
Returns either last value sent to
specified module by #AA
command, or start-up output
current/volta
e
6-20
$AA7CnRxx
Set Output T
pe Set CHn Output T
pe
6-20
$AA8Cn Current Readback Returns measured value of the
current/voltage flowing through
current loop
6-21
$AAF Read Firmware
Version
Return the firmware version code
from the specified analog output
module
6-21
$AAM Read Module
Name
Return the module name from the
specified analog output module
6-21
