Command
ASCII Command
(host to unit)
Response
(unit to host)
Additional Description
Set DNS server
IP address
E X1$
DI
}
Ipd
•
X1$
]
Set the DNS server IP address.
View DNS server
IP address
E
DI
} X1$
]
View the DNS server
IP address.
Set IP address,
subnet mask,
gateway
E X57^
*
X1$
*
X1(
*
X1%
CISG
}
Cisg1*IP/subnet bits*gateway
]
View IP address,
subnet mask,
gateway
E X57^
CISG
}
IP/subnet bits*gateway
]
Ping a remote IP
address
E X58^
PING
} X58&
]
Set global IP port
timeout
E
1*
X6(
TC
}
Pti0
*
X6(
]
View global IP port
timeout
E
1
TC
} X6(
]
RS-232 Port
Set RS-232 port
mode
E X!
*
X5)
HSTM
}
Hstm
X!
*
X5) ]
View RS-232 port
mode
E X!
HSTM
}
X5) ]
Configure serial port
parameters
EX!
*
X2%
,
X2^
,
X2&
,
X2*
CP
}
Cpn
X!•
Ccp
X2%
,
X2^
,
X2&
,
X2*]
Reset serial port
E X!
*9600,n,8,1CP
}
Cpn
X!•
Ccp
X2%
,
X2^
,
X2&
,
X2*]
View serial port
settings
E X!
CP
} X2%
,
X2^
,
X2&
,
X2*
]
Set current port
timeout
E
0
*
X6(
TC
}
Pti
0
*
X6(
]
View current port
timeout
E
0
TC
} X6(
]
NOTES:
X! = Port number Two digits, zero padding
X1$ = IP address (xxx.xxx.xxx.xxx) Default IP address = 192.168.254.254
X1% = Gateway address Default gateway IP address = 0.0.0.0
X1( = Subnet mask Default subnet mask = 255.255.0.0
X2% = RS-232 baud rate 300 to 115200 bps, default: 9600
X2^ = RS-232 parity Default: none
X2& = RS-232 data bits Default: 8
X2* = RS-232 stop bits Default: 1
X5) = RS-232 direct access mode 0=disabled, 1=host control, 2=direct access:pass-through
X6( = Port timeout in seconds zero padding, example: 000050
X57^ = Network interface ID First NIC=1
X58^ = IP address or URI
X58& = Ping result IP address*Bytes*TTL*time (in mS)
Command and Response Table for Basic SIS Commands (continued)
72SMD101 • Remote Communication and Control
