3... INTERFACE MODULES
USING THE OMP-MODL 3-19
MLIM-1; FOUR CHANNEL ANALOG INTERFACE MODULE
Overview:
The MLIM-1 is a four channel add-on Interface Module for use in conjunction
with the OMP-MODL System Base.
NOTE: The MLAD-1 module of the System Base
includes the functionality of the MLIM-1 in additon to its
other functions. This section’s configuration and
operation instructions pertain to both the MLIM-1 add-on
module and the MLAD-1 component of the System Base.
Each of the four channels can be individually programmed for any
combination of the following signal types and input ranges with HyperWare
software (via HyperNet) and hardware Configuration Switches (located on
the Interface Module).
Thermocouple:
DC Voltage:
Full Scale (FS) ranges:
Input Impedance for the 5V, 10V, and 30V ranges is >2.5Megohm.
All other range’s input impedance is > 10 Megohm.
Type Color (USA) Range (F) Range (C)
J white/red -60 to 1400F -50 to 760C
K yellow/red 32 to 2500F 0 to 1370C
E purple/red -150 to 1830F -100 to 1000C
T blue/red -250 to 750F -160 to 400C
R black/red 32 to 1830F 0 to 1000C
S black/red 32 to 3182F 0 to 1750C
Table 3... -1: Thermocouple input types and ranges
Icon Full Scale Input Ranges
VDC-LO +/- 20mV +/-40mV +/-50mV +/-60mV +/-100mV
+/-200mV +/-1V +/-2V
VDC-MED +/-5 V +/- 10V
VDC-HI +/- 3V +/-15V +/-30V
Table 3... -2: DC Voltage input ranges
