Hammer Quick Reference Guide
Item #
1191VSR(K) 1194VSR(K) 1199VSR(K) 11258VSR 11250VSR 11221DVS 11253VSR
Drive System
Round Round Round SDS-plus® SDS-plus® SDS-plus® SDS-plus®
Hammer
Classification
Hammer Drill Hammer Drill Hammer Drill Rotary Rotary
Combination Combination
Amperage 7 8 8.5 4.8
6 6.9 7.2
Impact Energy
(ft.-lbs.)
N/A N/A N/A 1.6 1.6 1.6 2.2
Max. Concrete
Capacity
5/8" 3/4" 3/4" 5/8" 3/4" 7/8" 1"
Optimal Range 1/8" - 5/16" 1/8" - 3/8" 1/8" - 3/8" 1/8" - 5/16" 5/32" - 5/8" 3/16" - 5/8" 3/16" - 5/8"
Core Bits N/A N/A N/A N/A 1-1/2" 2-1/2" 2-1/2"
No Load RPM 0-3,000
0-1,000 /
0-2,600
0-1,100 /
0-3,000
0-1,700 0-1,100 0-1,040 0-1,300
No Load BPM 0-48,000
0-16,000 /
0-41,600
0-18,000 /
0-48,000
0-4,400 0-4,400 0-5,750 0-5,800
Modes of
Operation
Rotation Only
Hammer Drill
Rotation Only
Hammer Drill
Rotation Only
Hammer Drill
Rotation Only
Rotary Hammer
Rotation Only
Rotary Hammer
Rotation Only
Rotary Hammer
Hammer Only
Rotation Only
Rotary Hammer
Hammer Only
Length 11" 16" 13.25" 11.9" 13.25" 16.5" 14.8"
Weight 4.1 lbs. 5.3 lbs. 6 lbs. 4.6 lbs. 5.4 lbs. 8.5 lbs. 6.4 lbs.
Item #
11224VSR(C)* 11255VSR 11239VS 11236VS 11222EVS(G) 11320VS
Drive System
SDS-plus® SDS-plus® SDS-plus® SDS-plus® SDS-plus® SDS-plus®
Hammer
Classification
Combination Combination Combination Combination Combination Chipping
Amperage 6.9 7.2 7.2 7.5
7.8 6.5
Impact Energy
(ft.-lbs.)
1.6 2.2 2.4 2.6 2.6 3.2
Max. Concrete
Capacity
7/8" 1" 1" 1-1/8" 1-1/8" N/A
Optimal Range 3/16" - 5/8" 3/16" - 5/8" 3/16" - 3/4" 1/4" - 7/8" 1/4" - 7/8" N/A
Core Bits 2-1/2" 2-1/2" 3" 3" 3" N/A
No Load RPM 0-1,100 0-1,300 0-1,050 0-850 300-700 N/A
No Load BPM 0-6,150 0-5,800 0-4,000 0-3,900 1,650-3,900 N/A
BPM N/A N/A N/A N/A N/A 3,500
Modes of
Operation
Rotation Only
Rotary Hammer
Hammer Only
Rotation Only
Rotary Hammer
Hammer Only
Rotation Only
Rotary Hammer
Rotation Only
Rotary Hammer
Hammer Only
Rotation Only
Rotary Hammer
Hammer Only
Hammer Only
Length 17.5" 17.3" 12.9" 15.25" 15.25" 14.75"
Weight 6.5 lbs. 6.7 lbs. 7.8 lbs. 9.3 lbs. 10.1 lbs. 7.9 lbs.
*11224VSRC Includes 3 Jaw Chuck
