Boschtools.com
Toll Free: 877-BOSCH-99
See page 44 for
hammer drill accessories.
BOSCH
Specifications
Rating 120V AC
Amperage 8.0
No Load RPM 0-1,000 / 0-2,600
No Load BPM 0-16,000 / 0-41,600
Spindle Size 1/2"-20"
Maximum Capacities (in.)
Concrete 3/4" /3/8" in 2nd
Steel 1/2" /1/4" in 2nd
Wood 1-1/2"
Aluminum 5/8" /3/8" in 2nd
Length (in.) 16"
Weight (lbs.) 5.3
Includes
360° Auxiliary Handle ........... 1 612 025 024
Depth Gauge .......................... 1 613 001 010
Chuck Key ..........................................CRK005
1194AVSRK
Carrying Case ........................ 2 605 438 284
Features
• 8.0 Amps, 0-1000/2600 RPM,
0-16,000/0-41,600 BPM
• 2 Speed gear box - Matches speed and torque
to the job
• Dual function control - Quickly converts from
rotation-only to hammer with rotation
• Variable Speed Reversing Switch - Complete
control for drilling, driving and removing bits
or screws
• All ball and roller bearing construction - Smooth
Power transmission and extended tool life
• Ergonomic handle - Multiple gripping positions
for increased comfort and control
• 360° Side-handle with depth gauge - Wide range
of movement along with consistent drilling depth
• Lock-on Button
1194AVSR(K)
1/2" Dual Torque Hammer Drill
Carrying Case
Included
Carrying Case
Included
Specifications
Rating 120V AC
Amperage 7
No Load RPM 0-3,000
No Load BPM 0-48,000
Spindle Size 1/2"-20
Maximum Capacities (in.)
Concrete 5/8"
Steel 1/2"
Wood 1-1/2"
Aluminum 5/8" /3/8" in 2nd
Length (in.) 11.0"
Weight (lbs.) 4.2
Includes
360° Auxiliary Handle ........... 2 602 025 094
Depth Gauge .......................... 2 603 001 009
Chuck Key ............................... 3 608 571 511
1191VSRK
Carrying Case ..................................Included
Features
• Light Weight Design - Perfect for small diameter
drilling applications
• 7 AMP Motor - Provides the highest performance
to weight ratio in its class
• 2-Mode Selector - Easily coverts from rotation only
to hammer drill
• Compact Design - Aggressive impact mechanism
in combination with a more powerful motor
outperforms the competition
• 360° Auxiliary Handle with Built-in Quick Release
Depth Gauge
• Variable Speed Trigger
• 1/2" 3-Jaw Chuck - For rugged hammer
drilling applications
1191VSR(K)
Hammer Drill
See page 44 for
hammer drill accessories.
BOSCH
Hammer Drills
