Toll Free: 877-BOSCH-99
Boschtools.com
See pages 44–47, 203–208 for
SDS-plus® accessories.
BOSCH
Specifications
Rating 120V
Amperage 7.5
No Load RPM 0-850
No Load BPM 0-3,900
Impact Energy (ft./lbs.) 2.6
Maximum Capacities (in.)
Concrete 1-1/8"
Concrete-Thin Wall Core Bit 3"
Steel 1"
Wood 1-1/4"
Optimal Concrete Capacity Range (in.)
1/4"-7/8"
Length (in.) 15-1/4"
Weight (lbs.) 9.3
Includes
Auxiliary Handle ..................... 2 602 025 077
Depth Gauge .......................... 1 613 001 003
Carrying Case ........................ 2 605 438 389
Features
• SDS-plus® bit system - Tool-free bit changes
with automatic bit locking, dust protection and
maximum impact energy transfer rate
• Multi-function selector - 3 modes of operation,
rotation only, rotary hammer and hammer
only mode
• Variable speed 3 finger trigger - Better operator
control and accurate bit starting
• Vario-Lock™ positioning - Rotates and locks
chisel into 36 different positions to optimize
working angle
• Padded rear handle - Absorbs shock for
operator comfort
• 360° Auxiliary handle with built-in depth
gauge - Wide range of movement along with
consistent drilling depth
• Integral clutch - Helps minimize torque reaction
11236VS
1-1/8" SDS-plus® Rotary Hammer
Carrying Case
Included
See pages 44–47, 203–208 for
SDS-plus® accessories.
BOSCH
Specifications
Rating 120V
Amperage 7.8
No Load RPM 300-700
No Load BPM 1,650-3,900
Impact Energy (ft./lbs.) 2.6
Maximum Capacities (in.)
Concrete 1-1/8"
Concrete-Thin Wall Core Bit 3"
Steel 1/2"
Wood 1-1/4"
Optimal Concrete Capacity Range (in.)
1/4"-7/8"
Length (in.) 15-1/4"
Weight (lbs.) 10.1
Includes
Auxiliary Handle ..................... 2 602 025 077
Depth Gauge .......................... 1 613 001 003
Carrying Case ........................ 2 605 438 376
Features
• SDS-plus® bit system - Tool-free bit changes
with automatic bit locking, dust protection and
maximum impact energy transfer rate
• Multi-function selector - 3 modes of operation,
rotation only, rotary hammer and hammer
only mode
• Variable-speed dial - For accurate bit starting
and controlled chipping applications
• Constant-Response™ Circuitry - Provides
soft-start, maintains constant speed under
load, provides overload protection
• Service Minder™ light - Indicates when
preventative maintenance is required
• Vario-Lock™ positioning - Rotates and locks
chisel into 36 different positions to optimize
working angle
• Padded rear handle - Absorbs shock for comfort
• 360° Auxiliary handle - Provides a wide range of
movement along with operator comfort
• Integral clutch - Helps minimize torque reaction
11222EVSG also features
• Grounded feature designed for the pest
control industry
• The best speed for the diameter of bits used by
the pest control industry
11222EVS(G)
1-1/8" SDS-plus® Rotary Hammer
Carrying Case
Included
Rotary Hammers
See pages 44–47, 203–208 for
SDS-plus® accessories.
BOSCH
Specifications
Rating 120V
Amperage 7.2
No Load RPM 0-1,050
No Load BPM 0-4,000
Impact Energy (ft./lbs.) 2.4
Maximum Capacities (in.)
Concrete 1"
Concrete-Thin Wall Core Bit 3"
Steel 7/8"
Wood 1"
Optimal Concrete Capacity Range (in.)
3/16"-3/4"
Length (in.) 12.9"
Weight (lbs.) 7.8
Includes
Auxiliary Handle ..................... 2 602 025 112
Depth Gauge .......................... 1 613 001 003
Carrying Case ........................ 2 605 438 482
Features
• SDS-plus® bit system - Tool-free bit changes
with automatic bit locking, dust protection and
maximum impact energy transfer rate
• Variable speed 3 finger trigger - Better operator
control and accurate bit starting
• Dual mode selector - 2 modes of operation,
rotation only and rotary hammer mode
• Innovative service modules - Designed so a
qualified service technician can quickly replace
the brushes and cord
• Padded rear handle - Absorbs shock for
operator comfort
• 360° Auxiliary handle with built-in depth
gauge - Wide range of movement along with
consistent drilling depth
• Integral clutch - Helps minimize torque reaction
11239VS
1" SDS-plus® Rotary Hammer
Carrying Case
Included
