Functional Description and Specifications
Disconnect the plug from the power source before making any
assembly, adjustments or changing accessories. Such preventive safety
measures reduce the risk of starting the tool accidentally.
!
WARNING
Circular Saw
FIG. 1
Blade 7-1/4" Maximum Capacities
Blade arbor hole Diamond Depth of cut at 90° 2-3/8"
Depth of cut at 45° 1-15/16"
Depth of cut at 50° 1-13/16"
NOTE: For tool specifications refer to the nameplate on your tool.
DEPTH ADJUSTMENT
LEVER
LOWER GUARD
LIFT LEVER
LOWER GUARD
CALIBRATED
BEVEL
QUADRANT
BEVEL
ADJUSTMENT
LEVER
UPPER
GUARD
AUXILIARY
HANDLE
TRIGGER
SWITCH
SAW HOOK
To use, simply lift up hook
until it snaps into the
open position.
When not in use, always
lower hook until it snaps
into the closed position.
FOOT
LOCK
BUTTON
OIL
PLUG
ALIGNMENT
SCREW
45º
STOP
SPRING
CALIBRATED
DEPTH BRACKET
Calibrated For
Standard Lumber Sizes
