PRODUCT SPECIFICATIONS
SAVE THIS MANUAL
You will need this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures, parts list and assembly
diagram. Keep your invoice with this manual. Write the invoice number on the inside
of the front cover. Keep this manual and invoice in a safe and dry place for future
reference.
GENERAL SAFETY RULES
READ AND UNDERSTAND ALL INSTRUCTIONS
Failure to follow all instructions listed below may result in
electric shock, fire, and/or serious injury.
SAVE THESE INSTRUCTIONS
WORK AREA
1. Keep your work area clean and well lit. Cluttered benches and dark areas
invite accidents.
2. Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases, or dust. Power tools create sparks
which may ignite the dust or fumes.
SKU 90186 PAGE 2
ITEM DESCRIPTION
Electrical 110V / 60 Hz / 13 Amp / 4500 RPM
Single Phase / Easy Access Carbon Brushes (Qty. 2)
Saw Blade Capacity 7-1/4” Diameter
Blade Arbor Hole Diamond
Depth of Cut 2-1/4”
Additional Features Two Handle Design / Spring Loaded Blade Guard /
Safety Switch / 5/8” Arbor Adapter
Overall Dimensions 18-1/2”L x 7-1/8”W (at its widest point)
Shoe Plate Size 11-13/16”L x 5-3/16”W
Weight 15.85 Pounds
WARNING
