Page 11For technical questions, please call 1-800-444-3353.SKU 95004
OPERATING INSTRUCTIONS
Read the ENTIRE IMPORTANT
SAFETY INFORMATION
section at the beginning of this
manual including all text under
subheadings therein before set up
or use of this product.
Tool Set Up
TO PREVENT
SERIOUS INJURY
FROM ACCIDENTAL
OPERATION:
Turn the Trigger of the tool off
and unplug the tool from its
electrical outlet before adjusting
tool or installing accessories.
To Install A Saw Blade:
CAUTION! To avoid accidental cuts to
hands and ngers, always wear heavy
duty work gloves when installing Saw
Blades (20).
SPINDLE
LOCK (39)
1.
the Spindle stationary.
OUTER PLATE
(18)
SCREW
(48)
HEX
WRENCH
(69)
SAW BLADE
(20)
2. Use the accessory Hex Wrench (69) to
unscrew and remove the Screw (48).
Remove the Outer Plate (18).3.
BLADE
HOUSING (11)
SAFETY
COVER (26)
4. Raise up on the Safety Cover (26).
Then, install the Saw Blade (20) on the
Spindle of the tool.
IMPORTANT: When installing a Saw Blade
(20), make sure the teeth of the Saw
Blade point upward and that the direction
of the arrow shown on the Saw Blade
matches the direction of the arrow
shown on the Blade Housing (11).
Release the Safety Cover (18), and allow 5.
it to return to its original position.
6.
the accessory Hex Wrench (69) to rmly
