Page 14For technical questions, please call 1-800-444-3353.SKU 95004
MAINTENANCE AND
SERVICING
Procedures not specically
explained in this manual must
be performed only by a qualied
technician.
TO PREVENT
SERIOUS INJURY
FROM ACCIDENTAL
OPERATION:
Turn the Power Switch of the tool
off and unplug the tool from its
electrical outlet before
performing any inspection,
maintenance, or cleaning
procedures.
TO PREVENT SERIOUS INJURY
FROM TOOL FAILURE:
Do not use damaged equipment.
If abnormal noise or vibration
occurs, have the problem
corrected before further use.
Cleaning, Maintenance, and
Lubrication
BEFORE EACH USE,1. inspect the
general condition of the tool. Check for
loose screws, misalignment or binding of
moving parts, cracked or broken parts,
damaged electrical wiring, and any
other condition that may affect its safe
operation.
Before each use, 2. inspect the Saw
Blade (20). Using a dull Saw Blade will
cause excessive wear on the Motor of
the Circular Saw and will not produce
a satisfactory cut. Replace with a new
Saw Blade when needed.
“AAA” BATTERIES
(QTY. 2)
FIGURE J
3. To replace the Batteries for the Laser:
two “AAA” Batteries. To replace the
Batteries:
a.
expose the Batteries.
Remove the old Batteries.b.
Then, install two fully charged “AAA” c.
Batteries, making sure to match the
Compartment.
d.
To clean or replace the Carbon 4.
Brushes (60): Clean or replace the
two Carbon Brushes when the Motor
performance decreases, or stops
working completely. The Carbon
Brushes are located on each side of the
Housing (57).
Unscrew and remove the two Carbon a.
Brush Covers (61) located on each side
of the Housing (57).
Remove the two Carbon Brushes (60) b.
from the two Brush Holders (59).
If the Carbon Brushes (60) are worn c.
down more than 1/2, replace both
Carbon Brushes. If, however, the
Carbon Brushes are just dirty they may
be cleaned by rubbing them with a
pencil eraser.
