A-2
Cisco 819 Integrated Services Router Hardware Installation Guide
OL-23125-02
Appendix A Technical Specifications
Router Specifications
Maximum Power
Consumption
11 W 20 W
Environmental Operating Ranges
Operating Temperature and
Altitude
–13 to 140°F
(–25 to 60°C)
32 to 104°F
(0 to 40°C)
–13 to 140°F
(–25 to 60°C)
Derate max operating temperature 1.5°C per 1000 feet above 5000 ft
10,000 ft maximum
Humidity Maximum 95%
non-condensing RH
Maximum 85%
non-condensing RH
Maximum 95% non-condensing
RH
Environmental Tests
Ingress Protection Rating IP 41 per IEC 60529 for
Vertical Falling Water,
Pollution Degree 3
IP 20 per IEC 60529 IP 41 per IEC 60529 for Vertical
Falling Water, Pollution Degree 3
Humidity Non-condensing Relative Humidity: 5% to 95%
Pollution Pollution 3 for Dust
Military Standard MIL-STD-810G Method 514.6: Procedure 1 Category 4, Secured Cargo - Common Carrier
MIL-STD-810G Method 514.6: Procedure 1 Category 20, Ground Vehicles
MIL-STD-810G Method 516.6. Procedure 1, Functional Shock
MIL-STD-810G Method 516.6. Procedure 5, Crash Hazard
MIL-STD-810G Method 516.6. Procedure 6, Bench Handling
Vibration and Shock
(Railway Vehicles)
EN61373 Functional Random Vibe - Category 1, Class B
EN61373 Simulated Non-op Long-life Vibe - Category 1, Class B
EN61373 Non-op Shock, Class B
Heavy-Duty Vehicle
Applications
SAE J1455 Operating Random Vibe, Cab Mounted Truck
SAE J1455 Operating Sinusoidal Vibe, Category 3
SAE J1455 Non-operating Sinusoidal Vibe, Category 3
SAE J1455 Handling Drop Test
Certifications
Standard Safety
Certifications
UL 60950-1, 2nd edition; CAN/CSA C22.2 No. 60950-1,
2nd edition, EN 60950-1, 2nd edition; CB to IEC
60950-1, 2nd edition with all group differences and
national deviations
UL 60950-1, 2nd edition;
CAN/CSA C22.2 No. 60950-1, 2nd
edition, EN 60950-1, 2nd edition;
CB to IEC 60950-1, 2nd edition
with all group differences and
national deviations; S/NZS
60950-1, first edition
(Australia/New Zealand)
Table A-1 Cisco 819 ISR Specifications (continued)
Description
Hardened Design
Specification
(Cisco 819HG and Cisco
819HG-4G ISRs)
Non-Hardened Design
Specifications
(Cisco 819G and Cisco
819G-4G ISRs)
Hardened Design Specifications
(C819HGW and C819HWD ISRs)
