SPECIFICATIONS
Motor 1-3/4 HP Rated
Electrical 120 V~, 11 Amps, 3450 RPM, Single Phase, 60 Hz
Power Cord 3 prong grounded 14 AWG X 3C, double insulated, UL listed, 20’ long
Air Outlet Fitting 1/4” NPT barbed
Drive Type Direct
Pump Stage Single
Air Tank Size 4 Gal.
Pressure Range Pressure Switch On at 80 PSI; Pressure Switch Off at 115 PSI
Air Delivery 4.2 SCFM at 90 PSI; 5.2 SCFM at 40 PSI
Pressure Disconnect Automatically releases pressure if overloaded to 120 PSI
Oil Requirement Standard non-detergent 30 weight compressor or motor oil
Weight 51 Lbs.
Page 2 SKU # 38898
NOTICE
The Warnings, Cautions, and Instructions discussed in this instruction manual cannot
cover all possible conditions and situations that may occur. It must be understood by the
operator that common sense and caution are factors which cannot be built into this prod-
uct, but must be supplied by the operator.
Warning: Fill compressor with oil before using;
running with NO or LOW OIL voids warranty.
Optimal oil tank capacity is 7.8 ounces.
REV 08/01; 01/02; 03/04; 11/04; 10/05; 02/06
Note: When using extensions cords (not included) - To avoid circuit breaker and
voltage drop problems, we recommend using only 12 gauge x 50 foot extension
cords (Item #41444 or #45287), available from Harbor Freight Tools).
FEATURES OF THIS COMPRESSOR
1. This small, portable compressor is ideal for use in shops with limited storage space.
2. 80-115 PSI operating range is ideal for most shop uses including air tools, spraying,
tire inflation, air cleaning, etc.
3. Pressure switch maintains correct operating pressure at all times.
4. Pressure gauge gives continuous, real-time readout of current pressure delivery.
5. Maximum pressure disconnect safety valve prevents over-pressurization of tank.
6. Delivers enough air for continuous use in most applications.
7. Sturdy construction will deliver years of satisfactory service.
8. Your compressor is fully assembled when you receive it.
SAVE THIS MANUAL
You will need the manual for the safety warnings and cautions, assembly instructions, operating
procedures, maintenance procedures, trouble shooting, parts list, and diagram. Keep your invoice
with this manual. Write the invoice number on the inside of the front cover. Keep both this manual
and your invoice in a safe, dry place for future reference.
