Page 7 SKU # 38898 Rev 03/00 REV 11/01 REV 03/04
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS DIAGRAM IN THIS
MANUAL AS A REFERENCE TOOL ONLY: NEITHER THE MANUFACTURER NOR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR
SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT OR THAT HE OR SHE IS
QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT: IN FACT THE MANUFACTURER AND/
OR DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS
SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS AND NOT BY THE
BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS
TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS
OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Compressor Assembly
MAINTENANCE
1.
Check the oil before each use to be sure the level of oil is correct (see illustration on page 5). If
the oil level is too low, add oil. If it is too high, drain some oil out by removing the drain plug.
2. Drain and replace the oil once per year. Replace more often if the compressor is used heavily or
the oil appears dirty.
3. Check the air filter every six months, or more often if compressor is used in a dirty or dusty
environment. Replacement air filters are available from Harbor Freight Tools.
4. Drain the air tank after each use, by turning the drain petcock clockwise to open it. Turn the
petcock counterclockwise to close it. It is a good practice to leave the drain plug open between
uses to ensure that the tank remains dry.
5. Never use flammable liquids or solvents to clean the compressor. For cleaning, unplug the unit,
and clean with a mild detergent and water. Be careful not to introduce water into any electrical
components.
Part # Description
1 Screw
2 Screw
3 Washer
4 Washer
5 Air Filter
6 Cylinder Case
7 Gasket, Crankshaft Cover
8 Valve Seat
9 Gasket, Valve Seat
10 Valve Plate
11 Valve Seat
12 Gasket, Valve Seat
13 Cylinder
14 Cylinder Gasket
15 Compression Ring
16 Scraping Oil Ring
17 Piston
18 Piston Pin
19 Crankshaft Retainer
20 Oil Stick
21 Screw
Part# Description
22 Connecting Rod
23 Crankshaft
24 Gasket, Front Cover
25 Front Cover
26 Washer
27 Washer
28 Bolt
29 Screw
30 Crankshaft Case
31 Nut
32 Seal Washer
33 Bearing
34 Electric Capacitor
35 Bolt
36 Screw
37 Motor
38 Washer
39 Radiating Fan Wheel
40 Radiating Cover
41 Thermal Switch
