SKU 42528 Page 9For technical questions, please call 1-800-444-3353.
Parts List
Part # Description
A-01 Body
A-02 O-Ring
A-03 Bottom Cap
A-04 Air Plug
A-05 Bumper
A-06 Cylinder
A-07 O-Ring
A-07-1 O-Ring
A-08 Collar
A-09 Valve
A-09-1 Stopper
A-09-2 O-Ring
A-09-3 O-Ring
A-10 O-Ring
A-11 Cylinder Cap
A-12 Seal
A-13 Spring
A-14 Cap
A-14-1 Screw
A-17 O-Ring
A-18 Seal
A-19 Seal
A-20 Trigger Valve
A-21 Valve Stem
A-22 O-Ring
A-23 Valve Guide
A-24 O-Ring
A-25 Spring
Part # Description
A-26 Trigger
A-27 Pin
A-28 E-Ring
A-29 Nozzle Cap
A-30 Pin
A31 Connecting Plate
3-1 Magazine Side Cover
3-2 Magazine Unit
3-3 Cover
3-4 Spring
3-5 Pusher Guide
3-6 Pusher
3-7 Support
3-8 Magazine Latch
3-9 Driver Guide
3-10 Driver Guide Cover A
3-11 “S” Connecting Plate*
3-12 Fore Stopper
3-13 Screw
3-14 Screw
3-15 Screw
3-16 Screw
3-17 Screw
3-18 Driver Blade
3-19 Safety Rod
3-20 Snap Ring
3-21 Spring
Maintenance
Warning! Always disconnect the tool from the air compressor and then empty the magazine
of nails before attempting to inspect or perform maintenance to the Nailer.
1. Inspect all of the nuts and screws and make sure they are securely fastened.
2. Periodically lubricate the driving mechanism and magazine with a light oil. Wipe down
with a clean cloth. Never use gasoline or flammable solvents to clean the tool.
3. Inspect your air compressor according to manufacturer’s instructions.
*Referred to as the Nose Piece throughout this manual.
