SKU 46225 For technical questions, please call 1-800-444-3353. Page 2
Specifications
Save This Manual
You will need the manual for the safety warnings and precautions, assembly in-
structions, operating and maintenance procedures, parts list and diagram. Keep
your invoice with this manual. Write the invoice number on the inside of the front
cover. Keep the manual and invoice in a safe and dry place for future reference.
Safety Warnings and Precautions
WARNING: When using tool, basic safety precautions should always be fol-
lowed to reduce the risk of personal injury and damage to equipment.
Read all instructions before using this tool!
1. Keep work area clean. Cluttered areas invite injuries.
2. Observe work area conditions. Do not use machines or power tools in damp
or wet locations. Don’t expose to rain. Keep work area well lighted. Do not use
electrically powered tools in the presence of flammable gases or liquids.
3. Keep children away. Children must never be allowed in the work area. Do
not let them handle machines, tools, or extension cords.
4. Store idle equipment. When not in use, tools must be stored in a dry location
to inhibit rust. Always lock up tools and keep out of reach of children.
5. Do not force tool. It will do the job better and more safely at the rate for which
it was intended. Do not use inappropriate attachments in an attempt to exceed
the tool capacity.
ITEM
Overall Dimensions
Table Dimensions
Water Tray Dimensions
Cut Capacity
Blade Specs.
(Blade not included)
Motor Specs.
Construction
Cord Specs.
Pump Max. Flow
Net Weight
DESCRIPTION
39-3/4”L x 21”W x 48-3/4”H
16-3/8” x 11-1/8”
35-1/4” x 18-1/2” x 3”D (outside)
Rips, 18”; Diag., 12”; Depth, 3-3/4”
10” Continuous Rim Blade (not
included), 0.050” Thick, Metal
Bonded Diamonds
3340 RPM, 2-1/2 HP, 115 V/120V, 60
HZ, 15 Amps, 1800 Watts, Single Phase
Low Carbon Steel and Cast
Aluminum
3-Prong Plug, Double Insulated, 6’L,
14 AWG, UL Approved
10-12 liters per minute
107 Lbs.
10 NJ
E180772
REV 02/06, 08/06
