SKU 66902 For technical questions, please call 1-800-444-3353. Page 10
Full Sequential Safety Trip
Mechanism Testing Procedure
TO PREVENT
SERIOUS INJURY
FROM ACCIDENTAL
OPERATION:
Empty the tool before this
procedure. Point the tool at a
piece of scrap wood when
testing.
Disconnect1. the tool from the air sup-
ply.
Empty the Magazine of fasteners.2.
Check that the Trigger and the Safety 3.
Nosepiece move freely, without stick-
ing.
Connect the air supply to the tool and 4.
set within the Operating Air Pressure
indicated on the Specication chart.
Test the tool by pressing the Safety 5.
Nosepiece against the workpiece
without pulling the Trigger. The Tool
must not cycle (re). If it cycles
(res), stop immediately and have it
repaired by a qualied service techni-
cian.
Hold the tool away or off of the work-6.
piece. The Safety Nosepiece should
return to its original position. Squeeze
the Trigger. The tool must not cycle
(re). If the tool res, stop immedi-
ately and have it repaired by a quali-
ed service technician.
Press the Safety Nosepiece against 7.
the workpiece and squeeze the
Trigger. The tool must cycle (re)
only once. Release the Trigger and
squeeze it again. The tool must
not cycle (re). With the Trigger
held, carefully lift the tool and press
it against the workpiece again. The
tool must not cycle (re). If it fails
to perform in the manner explained in
bold, have it repaired by a qualied
service technician.
Loading the Tool
TO PREVENT
SERIOUS INJURY
FROM ACCIDENTAL
OPERATION, BEFORE
LOADING:
• Wear ANSI-approved safety
goggles with side shields.
Other people in the work area
must also wear ANSI-approved
impact safety goggles.
Release the trigger.•
Detach the air supply.•
Attempt to re the Tool into •
a piece of scrap wood to
ensure that it is disconnected
and is incapable of ring any
fasteners.
TO PREVENT
SERIOUS INJURY
FROM ACCIDENTAL
OPERATION:
Release the trigger, detach the
air supply, and safely
discharge any residual air
pressure in the tool before
loading. Keep the Tool
pointed away from yourself
and others at all times. Do
not load fasteners with the
Trigger or Safety depressed.
Depress the Click Lever (74) to 1.
release the spring-loaded Magazine
(67) from the Magazine Cover (61).
Slide the Magazine out.2.
Rev 09d
