SKU 66902 For technical questions, please call 1-800-444-3353. Page 11
Insert the required size Fasteners 3.
(3/4” - 2” L 16-gauge Brad Nails or
1/2” - 1-1/2” L18-gauge Crown Nar-
row Staples) into the Magazine.
Slide the Magazine back into place 4.
until it clicks.
General Operating Instructions
Before each use, test the Tool, as 1.
directed in the prior section.
If an automatic oiler is not used, 2. add
a few drops of Pneumatic Tool Oil
to the airline connection before use.
Add a few drops more after each
hour of continual use.
Grip the Body (24) of the Nailer with 3.
both hands and press the nose piece
against the surface you wish to fas-
ten. Be sure to keep hands, ngers
and other body parts away from
Nozzle.
Push the nose piece on a scrap 4.
material, preferably the same thick-
ness and type of material as the
workpiece. Press the Trigger (42) to
activate the Nailer. Performing this
test-ring will help you to set the cor-
rect air pressure (not exceeding 90
PSI) to properly drive the fastener.
Grip the Body (24) of the Nailer with 5.
both hands and press the Nozzle
against the surface you wish to fas-
ten. Be sure to keep hands, ngers
and other body parts away from the
Nozzle.
Press the Trigger (42) to activate the 6.
Nailer.
To avoid indenting or marring when 7.
working on the face of ne surfaces,
use the supplied Plastic Cap (86) on
the Safety.
If the tool requires more force to 8.
accomplish the task, verify that the
tool receives sufcient, unobstructed
airow (CFM) and increase the
pressure (PSI) output of the regulator
up to the maximum air pressure
rating of this tool.
CAUTION! TO PREVENT TOOL
AND ACCESSORY FAILURE,
RESULTING IN INJURY:
Do not exceed the tool’s maximum
air pressure rating.
If the tool still does not have sufcient
force at maximum pressure and
sufcient airow, then a larger tool
may be required.
To prevent accidents, turn off the 9.
tool, detach the air supply, safely
discharge any residual air pressure in
the tool, and release the trigger after
use. Clean external surfaces of the
tool with clean, dry cloth, and apply
a thin coat of tool oil. Then store the
tool indoors out of children’s reach.
USER-MAINTENANCE
INSTRUCTIONS
Procedures not specically
explained in this manual
must be performed only by a
qualied technician.
TO PREVENT
SERIOUS INJURY
FROM ACCIDENTAL
OPERATION, BEFORE ANY
MAINTENANCE OR REPAIRS
ARE DONE (including clearing
jams):
Rev 09d, 09l
