Page 11SKU 95951 For technical questions, please call 1-800-444-3353.
Bottle Empty:6. During the Relling Process, if the Refrigerant Tank contains less
than 1 kg of uid, the process will stop and the indicator light will come on. The
bottle must be relled before continuing the Relling Process.
LCD Display
When the “kg” indicator light is on, the value shown in the LCD Display is the re-1.
covered or relled refrigerant weight.
When the “MIN” indicator light is on the LCD Display shows the Vacuuming Time 2.
in Minutes.
Valve Controls
LP Valve: 1. Low Pressure Control Valve.
HP Valve:2. High Pressure Control Valve.
Function Keys
“+” Key:1. Press this Key to adjust the setup value. Each press of the Key increases
the set value by 1.
“Circulate”:2. Press this Key to lock in the value set using the + Key.
“Recovering”:3. Press this Key to initiate the refrigerant recovery operation. Dur-
ing the Recovery operation, pressing this Key will toggle the LCD display between
“Setup Value” and “Actual Recovery Value.”
“Vacuumize”: 4. Press this Key to initiate the vacuum generation operation.
“Relling”:5. Press this Key to initiate the Relling operation.
“Start / Stop” :6. Press this Key to start or stop the current operation.
WARNING: Do not use any refrigerant other than factory specied R134A (also
identied as 134A, Forane 134a or HFC-134a) in an automotive A/C system.
Use of Freon or other Fluorocarbons is prohibited by US law.
WARNING: DO NOT INHALE or HANDLE REFRIGERANT. Inhalation of high concen-
trations of refrigerant is harmful and may cause heart irregularities, dizziness,
central nervous effects, unconsciousness or death. Intentional misuse or
deliberate inhalation may cause death without warning. Vapor reduces oxy-
gen available for breathing and is heavier than air. Decomposition products
of refrigerant are also hazardous. Contact with liquid refrigerant can cause
injury including frostbite.
REV 09h
