Page 2SKU 95951 For technical questions, please call 1-800-444-3353.
SPECIFICATIONS
Construction
Sheet Steel Housing, Reinforced Braided Rubber
Hoses with Brass Fittings, Polypropylene Valves,
Copper Tubing, Thermoplastic Oil Bottle and
Carbon Steel Hardware
Electrical Requirements 110 V~, 60 Hz
Compressor 1/3 HP Input Power
Vacuum Maximum Capacity 60 Liters per Minute (15.9 Gallons per minute)
Suitable for R134A Refrigerant
Refrigerant Tank Capacity 14 kg (30.8 lb)
Maximum Scale Weight 30 kg (66 lb)
Recovery Speed 250 Grams/Min (8.82 Ounces per Minute)
Relling Speed 800 G/Min (28 Ounces per Minute)
Overall Dimensions 18-1/8” W x 22” D x 43-1/8” H
Net Weight 160.8 lb.
Save This Manual
You will need this manual for the safety warnings and precautions, assembly, oper-
ating, inspection, maintenance and cleaning procedures, parts list and assembly diagram.
Keep your invoice with this manual. Write the invoice number on the inside of the front
cover. Write the product’s serial number in the back of the manual near the assembly
diagram, or write month and year of purchase if product has no number. Keep this manual
and invoice in a safe and dry place for future reference.
GENERAL SAFETY RULES
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS
Failure to follow all instructions listed below may result in
electric shock, re, and/or serious injury.
SAVE THESE INSTRUCTIONS
WORK AREA
Keep your work area clean and well lit. 1. Cluttered benches and dark areas invite
accidents.
Do not operate powered machines in explosive atmospheres, such as in the 2.
presence of ammable liquids, gases, or dust. Power machines create sparks
which may ignite the dust or fumes.
