Page 17SKU 95951 For technical questions, please call 1-800-444-3353.

PARTS LIST

For ease of understanding, the components of this machine are displayed in groups.

Each group is identied with a Roman Numeral. Components within each group are identi-

ed with the group numeral plus a part number. For example “IV-3” is Part 3 in Group IV.

Group I : Left Panel Assembly Group II : Bottom Panel Assembly

Group III : Front Panel Assembly Group IV : Right Panel Assembly

Group V : Control Panel Assembly Group VI : Back Panel Assembly

Part Description Q’ty

I-1 Left Side Panel 1

I-2 Load Cell Controller 1

I-3 Pressure Controller A 1

I-4 Mounting Bracket 1 1

I-5 Transformer 1

I-6 Pressure Controller B 1

I-7 Mounting Bracket 2 1

I-8 Hose Connector 4

I-9 Oil Charge Valve 1

I-10 Quick Coupler 1

I-11 Oil Bottle 1

I-12 Separator 1

I-13 Oil Drain Valve 1

II-1 Bottom Panel 1

II-2 Vacuum Pump 1

II-3 Caster Wheel 4

II-4 Compressor 1

II-5 Scale Weight Sensor 1

Part Description Q’ty

II-6 Mat 1

II-7 Scale Tray 1

II-8 Refrigerant Cylinder 1

III-1 Front Panel 1

III-2 Dryer and Filter 1

III-3 Separator 1

III-4 Solenoid 1

IV Right Side Panel 1

V-1 Control Panel 1

V-2 Main Control Board with LCD 1

V-3 Key Pad 1

V-4 High Pressure (HP) Gauge 1

V-5 Low Pressure (LP) Gauge 1

V-6 Cylinder Gauge 1

V-7 Low Pressure (LP) Valve 1

V-8 High Pressure (HP) Valve 1

VI-1 Back Panel 1

Please Read The Following Carefully

THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY

DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR

DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT

HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS

QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR

DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE

UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUY-

ER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL

PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION

OF REPLACEMENT PARTS THERETO.
