2. Battery Charger (UC10SFL)
Fig. 2
Nameplate
Caution plate
Body
Battery installation hole
Pilot lamp
SPECIFICATIONS
1. Cordless Driver Drill (DS10DFL)
2. Battery Charger (UC10SFL)
Motor DC motor
No-load speed
Low 0 – 300 / min
High 0 – 1,300 / min
Wood (Thickness
13/16" (21 mm)
Drilling
11/16" (18 mm))
Capacity
Metal (Thickness 3/8" (10 mm)
1/16" (1.6 mm)) (Mild Steel)
Screw Wood screw #12 × 1-25/32" (5.8 mm × 45 mm)
Driver Small screw 1/4" (6 mm)
Model BCL1015
Type Lithium - ion battery
Battery
Voltage DC 10.8 V/12 V Peak
Charging & discharging
About 1,000 times
frequency
Weight 2.2 lbs. (1.0 kg)
Input power source Single phase: AC 120 V 60 Hz
Charging time
Approx. 40 min.
(At a temperature of 68°F (20°C))
Charging voltage DC 10.8 V
Charging current DC 2.0 A
Weight 0.8 lbs. (0.35 kg)
NOTE: The charging time may vary according to temperature and power source voltage.
