SPECIFICATIONS
Model
Operating pressure
Dimensions
Length × Height × Width
Weight
Nail capacity
Air consumption
Air inlet
N5008AB N3804AB
70 – 120 psi (4.9 – 8.3 bar 5 – 8.5 kgf/cm
2
)
14 - 7/16" × 9 - 5/8" × 2 - 3/4" 9 - 23/32" × 8" × 2 - 7/32"
(367 mm × 244 mm × 70 mm) (247 mm × 203 mm × 56 mm)
5.5 lbs. (2.5 kg) 2.9 lbs. (1.3 kg)
156 Staples 125 Staples
.046 ft
3
/cycle at 100 psi .032 ft
3
/cycle at 100 psi
(1.3 ltr/cycle at 6.9 bar) (.9 ltr/cycle at 6.9 bar)
(1.3 ltr/cycle at 7kgf/cm
2
) (.9 ltr/cycle at 7kgf/cm
2
)
3/8" NPT Thread
STAPLE SELECTION
Only staples shown in the Table below can be driven with this Stapler.
Dimensions of staples
N5008AB N3804AB
16 Gauge 7/16" Crown 18 Gauge 1/4" Crown
Min. Max. Min. Max.
7.9mm
(.309")
1.45mm
(.057")
3.5mm
(.138")
1.08mm
(.043")
1.61mm
(.063")
50mm (2")
1.25mm
(.049")
38mm (1–1/2")
16mm (5/8")
25mm (1")
