Maintenance chart
ACTION WHY HOW
Drain air line filter daily. Prevent accumulation of moisture Open manual petcock.
and dirt.
Keep lubricator filled. Keep the Nailer lubricated. Fill with Hitachi pneumatic tool
lubricant.
Clean filter element — then blow Prevent clogging of filter with dirt. Follow manufacturer’s instructions.
air through filter in direction
opposite to normal flow.
Clean magazine and feeder Prevent a jam. Blow clean daily.
mechanism.
Keep push lever working properly. Promote operator safety and Blow clean daily.
efficient Nailer operation.
Lubricate the Nailer after nailing. Extend the Nailer life. Supply 2 – 3 drops of lubricant
into the Nailer.
Drain air compressor. Keep the Nailer operated properly. Open petcock on air compressor tank.
Operator troubleshooting
Most minor problems can be resolved quickly and easily using the table below.
If problems persist, contact a Hitachi authorized service center for assistance.
PROBLEM
Nailer operates, but no nail is driven.
Weak drive.
Slow to cycle.
Drives too deep.
Skipping nails. Intermittent feed.
Nails jam.
Driven nail is bent.
Drives properly during normal
operation, but does not drive fully
at faster nailing speeds.
CHECK METHOD CORRECTION
Check for a jam. Clear a jam.
Check function of nail feeder per Clean and lubricate.
page 15.
Ribbon spring weakend or damaged? Replace ribbon spring.
Check for proper nails. Use only recommended nails.
Check air pressure. Increase air pressure. (Do not
exceed 120 psi (8.3 bar 8.5 kgf/cm
2
))
——— Use Hitachi pneumatic tool lubricant.
Driver blade worn?
Piston ring worm or damaged?
Contact Hitachi for replacement.
Check air pressure. Reduce air pressure.
(Adjust 70 – 120 psi)
Check for proper nails. Use only recommended nails.
Check function of nail feeder per Clean and lubricate.
page 15.
Ribbon spring weakend or damaged? Replace ribbon spring.
——— Use Hitachi pneumatic tool lubricant.
Piston ring cut or heavily worm? Contact Hitachi for replacement.
Check for proper nails. Use only recommended nails.
Driver blade worm? Contact Hitachi for replacement.
Check inside diameter of air hose. Use larger air hose.
