— 47 —
Español
Item
Code No. Part Name Q'ty
No.
1 949-755 Hex. Socket Hd. Bolt M6×16 1
2 880-515 Plate 1
3 880-514 Top Cover 1
4 882-793 Hex. Socket Hd. Bolt M6×35 4
5 881-946 Exhaust Cover 1
6 881-940 Gasket (A) 1
7 881-945 Exhaust Valve Rubber 1
8 881-944 Head Valve Spring 1
9 887-124 Cylinder O-Ring (B) 2
10 881-942 Head Valve 1
11 877-315 Cylinder O-Ring (I.D 63.9) 1
12 881-943 Head Valve Rubber 1
13 881-941 Cylinder Plate 1
14 878-907 O-Ring (S-95) 1
15 887-376 O-Ring (I.D 59.3/W2.4) 1
16 881-972 O-Ring 1
17 881-939 Cylinder 1
18 881-930 Piston Ring 1
19 882-979 Piston 1
20 955-479
Retaining Ring
(E-Type) For D6 Shaft
1
21 878-184 Warning Label 1
22 881-938 Body Ass'y 1
23 – Nameplate 1
24 881-966 Piston Bumper (A) 1
25 881-967 Piston Bumber (B) 1
26 956-996 O-Ring (ISA-60) 1
27 882-970 Nose 1
28 949-759 Hex. Socket Hd. Bolt M8×30 4
29 949-864 Roll Pin D3×22 2
30 882-980 Spring 1
31 882-971 Pushing Lever (B) 1
32 881-974 Adjuster (A) 1
33 982-454 Spring (C) 2
34 959-155 Steel Ball D3.97 2
35 882-982 Pushing Lever (A) 1
36 880-081 Washer 1
37 949-657 Hex. Socket Hd. Bolt M6×12 1
38 881-768 Grip Tape (A) 1
39 880-407 Tape 2
40 881-769 Gasket (B) 1
41 881-949 Cap 1
42 949-821 Hex. Socket Hd. Bolt M5×16 3
43 872-035 Dust Cap 1
44 880-674 Trigger (A) 1
45 881-952 Trigger Pin 1
46 949-865 Roll Pin D3×28 2
47 880-361 Pushing Lever Guide 1
48 877-699 Head Valve O-Ring (I. D 16.8) 1
49 878-881 Valve Bushing (B) 1
50 878-885 O-Ring (S-18) 1
51 981-317 O-Ring (S-4) 1
52 880-672 Valve Piston (B) 1
53 878-925 O-Ring (I. D 8.8) 2
54 878-887 O-Ring (I. D 11) 1
Item
Code No. Part Name Q'ty
No.
55 878-884 Plunger Spring 1
56 880-673 Plunger (A) 1
57 878-888 O-Ring (I. D 1.8) 1
58 880-671 Valve Bushing (A) 1
59 880-474 Nylock Bolt (W/Flange) M6×16 2
60 882-972 Guard 1
61 882-973 Sleeve 1
62 963-837 Nylon Nut M6 4
63 882-976 Handle Arm 1
64 877-402 Wahser 2
65 882-978 Magazine Cover 1
66 882-977 Nail Feeder 1
67 878-635 Nail Rail 1
68 874-418 Needle Roller 1
69 878-422 Ribbon Spring 1
70 876-465 Nylon Nut M4 1
71 877-371 Nylon Nut M5 1
72 878-634 Stopper 1
73 878-637 Magazine Guard (B) 1
74 949-824 Hex. Socket Hd. Bolt M5×45 1
75 882-975 Magazine 1
76 878-646 Magazine Guard (A) 1
77 882-974 Nylock Bolt (W/Flange) M6×12 1
78 878-647 Hex. Socket Hd. Bolt M6×12 1
79 – Label 1
80 878-638 Stopper Spring 1
81 878-636 Collar 1
82 878-643 Stop Lever 1
83 949-699 Hex. Socket Hd. Bolt M4×20 1
501 882-981 Nose Cap (A) 1
502 943-277 Alllen Wrench 3MM 1
503 944-458 Allen Wrench 4MM 1
504 944-459 Allen Wrench 5MM 1
505 872-422 Allen Wrench 6MM 1
506A 875-769 Eye Protector 1
Parts are subject to change without any obligation on the
part of the HITACHI due to improvements.
