– 16 –
Hammer
Rod
Outlet
Slotted Screwdriver
Nail Guide
Nail guide
Knob
MAINTENANCE
NOTE:
The information contained in this Manual is designed to assist you in the safe maintenance of the Nailer.
Some illustrations in this Manual may show details or attachments that differ from those on your own Nailer.
MAINTENANCE AND INSPECTION
Read section titled "SAFETY" (page 4 – 6 ).
WARNING
ⅷ Disconnect air hose and remove all nails from Nailer when:
1) doing maintenance and inspection; and
2) clearing a jam.
ⅷ Never use gasoline or other highly flammable liquids for cleaning
1. Clearing a jam
Remove a jammed nail in the following order:
1 DISCONNECT AIR HOSE.
2 Open the nail guide
3 Insert a rod into the outlet.
Tap the rod with a hammer
4 Remove the jammed nail with a slotted screwdriver
5 Cut the deformed collated wire/plastic sheet with nippers. Correct the deformation.
6 In case of frequent jam, contact a Hitachi authorizes service center.
2. Inspect the feeders
1 DISCONNECT AIR HOSE.
2 Clean the knob sliding part.
Lubricate it with Hitachi pneumatic tool lubricant
